VITOCOLL
538 B09
double-sided tape
Double-sided adhesive tape based on a polyester film equipped with a modified acrylate on both sides. One side has high and the other side low adhesive strength.
Application
VITOCOLL 538 B09 is used for the residue-free removable bonding of products, for indoor and outdoor applications. The side with high adhesive strength is used for the adhesion of felt, film, paper, elastomer and tissue.
Product benefits
- the side with low adhesive strength can be removed from most surfaces like wood, PVC and metal without leaving any residue
- compatible with acrylic glass
Processing instructions
The most important processing parameters and information on cleaning are listed in our Information on Processing Adhesive Tapes. Processing
Storage and shelf live
12 months after receipt of goods, when stored non processed, at room temperature and 60 % relative humidity, in original packaging
product composition
composition du produit
Technical data and product properties
thickness
0,09 mm
Peel strength on steel, weakly adhesive side
i. A. DIN EN 1939
at 20 °C
1 - 2 N / 25 mm
Peel strength on steel, strongly adhesive side
i. A. DIN EN 1939
at 20 °C
17 N / 25 mm
Shear strength on steel, strongly adhesive side
i. A. DIN EN 1943
at 20 °C
15 N / 625 mm²
application temperature
15 °C to 30 °C
temperature resistance
-40 °C to 90 °C
compatibility with acrylic glass
passed
